              PC200 / PC201    P.I.R   Power   Control



@

@
  Features:    Specifications: @
@
  • PC200 Ac Power Control.
  • PC201 Relay Output Control (Max 5A)
  • Power  On/Off Switch.
  • Power LED Indicator.  (On=Red  Off=Green)
  • Time Control.
  • Lux  Control.
  • Power Off-Auto-On SW.

@

  • Input Voltage: 100V--250V.
  • Input Frequency: 50-60Hz.
  • Output Power: 500W (Max).
  • Relay Output: Max 5A/250AC.
  • P.I.R.Control Range : >7M .
  • Power Consumption: AC 1W.
  • Dimensions: 56*78*39mm(W*H*D).
  • Weight: 0.3Kgs (Net).

@

@
@
