MA3106 (F)(A)  (EIA 3U)   Professional  Multi-Channel Amplifier

• Power Switch.
• Signal Input Indicator.
• Auto On/Trigger On.
• Volume Control.
• Bridged Function.
• Speaker ON/OFF SW
• RCA  Line Input& Buss In.
• Speaker Jacks .
• IEC Power Input.

• Power Output (At 8 Ohms T.H.D < 1%):F=40W A=80W (Channel).
• Power Output (At 4 Ohms T.H.D < 1%):F=60W A=120W (Channel).
• Bridged Power Output (At 8 Ohms):F=120W A=200W(2/Channel Mono).
• Distortion: < 0.002%
• S/N Ratio (IEC-A): > 90db .
• Frequency Response (+/- 1db) : 10-40KHz.
• Dimensions: 483*132*380m(W*H*D).
• Weight: 9/14 Kgs (Net).
